Suitable for under and over-ground usage alike, 25mm 4 Core Armoured Cable is a dust and waterproof variant of electrical cable that is commonly found within powered networks and supplying mains electricity to a large variety of devices, both domestic and industrial.
This particular type of cable is constructed using Plain Annealed Stranded Copper for the conductors, XLPE (Cross-Linked Polyethylene) for the insulation, PVC (Polyvinyl Chloride) for the bedding and sheathing and Steel Wire for the armouring.
Not only does the Steel Wire Armour provide a method of mechanical protection, meaning it is suitable for installation into highly-corrosive environments, the armour also provides a form of CPC (Circuit Protective Conductor) meaning it can be used as an earth for the cable. This means that an earth core/cable is not required although it is still recommended as an extra safety measure.
No. of cores / size of cable – 4
Approx overall diameter – 18.7mm
Approx weight (m) – 0.75Kg
Conductors – Plain Annealed Stranded Copper
Insulation – Cross-Linked Polyethylene (XLPE)
Bedding – PVC
Armour / Protection – Steel Wire
Sheath / Jacket – PVC
Colour – Black
Application – Primarily found within powered networks and providing mains electricity to powered devices.
Voltage Rating – 600/1000Vt
