Specifications

General Information

Lamp family code	–
Light source color	740 neutral white
Light source replaceable	No
Number of gear units	1 unit
Driver/power unit/transformer	Power supply unit
Driver included	Yes
Optical cover/lens type	–
Control interface	–
Connection	–
Cable	–

Protection class IEC	Safety class I
Flammability mark	For mounting on normally flammable surfaces
CE mark	CE mark
ENEC mark	–
Warranty period	3 years
Optic type outdoor	–
Constant light output	No
Number of products on MCB of 16 A type B	11
Light source engine type	LED

Light Technical

Upward light output ratio	0
Standard tilt angle posttop	–

Standard tilt angle side entry

0°

Operating and Electrical

Input Voltage	220 to 240 V
Input Frequency	50 to 60 Hz
Inrush current	46 A

Inrush time	0.44 ms
Power Factor (Min)	0.9

Controls and Dimming

Dimmable

No

Mechanical and Housing

Housing Material	Aluminum die cast
Optic material	Polycarbonate
Optical cover/lens material	Polycarbonate
Fixation material	Aluminum
Mounting device	Side-entry for diameter 42 to 60 mm
Optical cover/lens shape	Ball, globular

Optical cover/lens finish	–
Overall length	492 mm
Overall width	295 mm
Overall height	86 mm
Effective projected area	0.14 m²
Color	Gray

Approval and Application

Ingress protection code

IP66  [ Dust penetration-protected, jet-proof]

Mech. impact protection code

IK08  [ 5 J vandal-protected]

Initial Performance (IEC Compliant)

Initial luminous flux (system flux)	14400 lm
Luminous flux tolerance	+/-5%
Initial LED luminaire efficacy	120 lm/W
Init. Corr. Color Temperature	4000 K

Init. Color Rendering Index	>70
Initial chromaticity	(0.43, 0.40) SDCM < 5
Initial input power	120 W
Power consumption tolerance	+/-5%

Over Time Performance (IEC Compliant)

Median useful life L70B50

100000 h

Application Conditions

Ambient temperature range

-30 to +50 °C

Maximum dim level

Not applicable

Product Data

Full product code	911401816498
Order product name	BRP392 LED144/NW 120W 220-240V DM
Order code	911401816498
Numerator – Quantity Per Pack	1

Numerator – Packs per outer box	1
Material Nr. (12NC)	911401816498
Net Weight (Piece)	6.200 kg
