Specifications

General Characteristics:
Housing – [Not Specified]
Lifetime – 50000 hr
Input Frequency – 50/60 Hz
Relative Humidity – 10 (min), 90 (max) %
IP Classification – 20
Lifetime 90% surv.@Tcaselife – 50000 hr
System Description – TD/TE [Touch&DALI/Trailing edge dimming]
Number of LEDs – x

Operating Characteristics
12V output – Yes
Ripple current – 20 %
Efficiency Range – 88-90 %
Power Factor Range – 0.9
Output Power Range – 15-50 W
Power Factor (100% load) – 0.9 (min) –
Output Voltage Range – 31-62 V
Output Current Range (mA) – 300-1000
Dimming range – 100-10 %
Dimmable – Yes
Input Voltage Range (DC) – 186-250 V
Inrush Current Peak – 48 (max) A
Output Current Tolerance – -5 (min), 5 (max) %
Inrush Current Width to 50% – 180 us
Type of Dimming – Touch&DALI and trailing edge
Input Voltage Range (AC) – 220-240 V
Earth leakage current – 0.7 (max) mA
Max drivers on MCB(16A type-B) – 12 (max) x
Control input protection – Yes (Basic insulation)

Wiring Characteristics
Connection on driver to L2 – JST connector
Hot wiring – Yes
Connector type input terminal – Wago 250
Connector type output terminal – Wago 250

Product Dimensions
Length A1 – 140.0 mm
Width B1 – 75 mm
Height C1 – 32 mm
Fixing Hole Diameter D1 – 4.5 mm
Fixing Hole Distance Width B2 – 63.7 mm
Fixing Hole Distance Length A2 – 128.5 mm
